Ferries (JFS)

The Matrix modular ferry (JFS) can be assembled entirely from standard components that are transported by road. The dimensions of the ferry can be determined based on the number of standard Matrix coupling pontoons. Everything is possible with the JFS!

The engine capacity used depends on the desired speed, the waterway data and the dimensions of the ferry. The ferry is designed according to the roll-on, roll-off principle with hydraulically controlled ramps on both sides.

Optional is the arrangement for separate pontoons to be uses for engine compartment, storage pontoon or bunker tank. The engines can be installed in drive pontoons or on the deck with standard surface-mounted engines.

JFS

Solution
Ferries
Type
JFS
Capacity
9 pieces of 3-axle trucks
Maximum speed
11 km/h with full load
Loaded draught
1,40m
Unloaded draught
0,55m
Load
320 tons
Engine power
2x 368 kW Marine Diesel engines
Tare weight
225 tons
Ramps
2 hydraulic ramps, 6.25 x 5m

Matrix’s ferry system (JFS)

  • Self-propelling ferry
  • For passengers and vehicles
  • Variable dimensions and speeds
  • Wheelhouse with an all-around view
